SHACMAN X3000 8X4 WEICHAI 480HP Dump Truck For Building Materials Transportation

SHACMAN X3000 Dump Truck Description

This is SHACMAN's higher-end truck, excelling in short-distance, high-intensity work such as mining, infrastructure construction, and waste transportation. Not only does it boast strong load-bearing capacity, but it also features a powerful 480-horsepower Weichai engine, easily handling complex road conditions and long uphill climbs. Thanks to its excellent design, it still has ample capacity even when fully loaded, making it a completely reliable commercial vehicle.

SHACMAN X3000 Dump Truck Specification

Product Name: SHACMAN X3000 Dump Truck

Application: Mining, Infrastructure Construction And Waste Ttransportation

Engine: WP13.480E30

Front Axle:MAN 9.5T

Rear Axle:16T MAN

Cabin: With one bed, A/C

Gearbox: 16JSD240TA

Tire: 12R20 ,12+1 pcs

Color: Optional

Fuel Tank: 400L

SHACMAN X3000 Dump Truck Diesel Engine

It is equipped with a WEICHI WP13.480E30 engine, an inline six-cylinder four-stroke engine. Peak torque reaches 353KW, maximum torque is 2300Nm, and low-speed torque response delay is less than 0.2 seconds, with no power loss during heavy-load starts or hill climbing. It can start directly without auxiliary equipment at -15 degrees Celsius, and can operate normally with intake preheating at -30 degrees Celsius. It maintains normal power at altitudes below 2000 meters, and power loss is less than 8% from 3000 meters to 2000 meters, demonstrating excellent adaptability to high-altitude and cold-weather conditions.

SHACMAN X3000 Dump Truck Reliability Configuration

Reinforced core components: alloy cylinder block (≥900MPa tensile strength, 30% higher deformation resistance), dry liners, wear-resistant coated pistons, and chrome-plated alloy piston rings (≥400℃ heat resistance) for extended life; optimized transmission with Fast 16JSD240TA gearbox (2400N·m max torque) and φ430 clutch (heat/wear-resistant plates) ensuring stable heavy-load shifting; reduced noise (≤81dB(A) idle) via drum-shaped cylinder skirt and precision shear gears; validated by 45,000+ hours of bench testing (no core failures) and 500,000+ km road testing (complex conditions), with ≤3% failure rate and ≥80,000km average trouble-free mileage.
