SINOTRUK HOWO TX 371HP 8X4 12 Wheels Tipper Truck

About SINOTRUK HOWO TX 371HP 8X4 12 Wheels Tipper Truck

The SINOTRUK tipper truck features large primary and secondary rearview mirrors, offering a wide illumination range and minimal blind spots. The lenses are electrically adjustable and heated. The front and right blind spot mirrors are strategically positioned and offer optimal illumination angles. Combined with the standard voice-activated turn signal system, these features effectively reduce blind spot hazards and enhance driving safety. A three-level entry and exit platform facilitates easy entry and exit. Made of aluminum alloy, the platform features large perforations and a non-slip tread surface, ensuring driver safety.

SINOTRUK HOWO TX 371HP 8X4 12 Wheels Tipper Truck Specification

Product Name: SINOTRUK HOWO TX 371HP 8X4 12 Wheels Tipper Truck

Application: Construction work

Engine: WD615.47, 371HP. Euro 2

Cabin: With one bed, A/C

Gearbox: 10 forward and 2 reverse gear

Tire: 12.00R20 ,12+1 pcs

Color: Optional

Fuel Tank: 300L

Cargo Box:7600X2300x1500mm

SINOTRUK HOWO TX 371HP 8X4 12 Wheels Tipper Truck only for your reference, we can manufacture other Tipper truck basic your request.

SINOTRUK HOWO TX 371HP 8X4 12 Wheels Tipper Truck Cabin

The HOWO 371HP tipper truck's cab features a sleeper berth, creating a spacious and comfortable working environment for both drivers and passengers. The driver's seat is ergonomically designed, offering excellent support and comfort, ensuring fatigue-free operation even during long hours. The functional area integrates numerous functions, including audio and video entertainment, Bluetooth phone answering and ending calls, and more. The interior's materials and workmanship are exceptionally refined, creating a high-end and elegant experience. The center console features a simple and clear design, with conveniently arranged function buttons and easy operation. The extensive entertainment and information systems provide enhanced convenience and driving pleasure.

SINOTRUK HOWO TX 371HP 8X4 12 Wheels Tipper Truck Gearbox

The 12 Wheels tipper truck uses a SINOTRUK designed transmission. The main transmission utilizes a dual-countershaft structure, while the auxiliary transmission utilizes a planetary transmission mechanism, significantly enhancing assembly reliability. The dual-countershaft structure of the main transmission splits power, with each intermediate shaft, its bearings at both ends, and its gears bearing only half the total power. This dual-countershaft structure reduces center distance, gear diameters, gear width, and shaft diameters, resulting in a shorter axial dimension and lighter weight. The auxiliary transmission utilizes a planetary transmission mechanism, effectively preventing premature failure of the auxiliary transmission and significantly extending the service life of the transmission assembly.
