High Capacity SINOTRUK HOWO TX 430HP 10 Wheels Dump Truck For Liberia

Introduction



The SINOTRUK HOWO TX 430-horsepower 10-wheel dump truck is a premium heavy-duty dump truck, meticulously engineered for the Liberian market to excel in both on-road and off-road operating conditions.

Whether navigating muddy construction sites during the rainy season or traversing flat, wide paved roads, it performs its transport duties with exceptional competence. Powered by a robust engine delivering high-torque traction, and equipped with an advanced dual-countershaft transmission system, it ensures superior transport efficiency.

It is particularly well-suited for large-scale infrastructure earthworks, civil construction projects, and the short-to-medium-distance transport of sand, gravel, aggregates, and building materials in and around Monrovia and other developing regions.





What is the SINOTRUK 430 HP 6x4 Dump Truck?



The SINOTRUK dump truck configured for the Liberian market integrates a high-torque 430 HP Weichai diesel engine, a premium 12-speed synchronized transmission, a high-ground-clearance chassis, and a high-strength manganese steel cargo box. It features the following key characteristics:

● HW25712XST heavy-duty 12-speed transmission (using helical gears, dual intermediate shafts, and full synchronizer design), ensuring smooth shifting and durability.

● 12.00R24 large-diameter tires, providing excellent ground clearance.

● MCP16ZG heavy-duty 16-ton rear axle, impact-resistant and with high load-bearing capacity.

● Engineering-grade oil bath air filtration system, efficiently filtering air.

● High-strength manganese steel cargo box, durable and wear-resistant.

This configuration ensures that the vehicle can handle rugged construction conditions and continuous high-load operations with ease, while also maintaining good speed performance on highways.





Technical Specifications



Feature	Value
Engine	WEICHAI WP12.430E201
Cab	TX-F Middle Long Cab With Single Sleeper
Drive Type	6X4
Gearbox	HW25712XST + HW50 PTO, 12F&2R
Chassis	Double Layer(8+8/300mm)
Front Axle	VGD95, 9.5 Tons
Rear Axle	MCP16ZG, 16 Tons, Ratio 5.26
Tire	12.00R24, Mixed pattern, 18PR
Fuel Tank	300L Aluminum Alloy
Cargo Box	5600 × 2300 × 1500 mm



Why It Is Suitable for Liberian Infrastructure Projects



1.Road Conditions in Liberia

Construction sites in Liberia during the rainy season often involve:

● Deep mud and rutted dirt tracks

● Mixed paved and unpaved routes

● Hidden rocks and debris on sites

● High risk of chassis bottoming out

The 12.00R24 tires provides superior ground clearance, while the high-position metal bumper with protection grilles shields the front end, significantly reducing the risk of getting stuck or damaged in deep ruts.



2.Climate and Environment Adaptability

Liberian operating environments typically feature:

● High humidity and frequent rain

● Dust-intensive construction sites

● Fluctuating local diesel quality

● High-temperature exposure

The engineering-grade oil-bath air filter effectively blocks fine dust from entering the engine. Combined with the highly tolerant WP12 Series Euro II engine, it ensures reliable operation and simple local maintenance.



3.Ideal for Heavy Sand and Earthworks

Transporting building materials and earthworks in developing regions requires:

● High chassis rigidity for overloading

● Resistance to aggregate wear

● Maximized legal payload

● Stable unloading on uneven ground

The 8+8/300mm double-layer reinforced frame provides exceptional bending resistance, while the 19.3 cbm manganese steel cargo box (bottom 8mm, side 6mm) maximizes load-bearing capacity and wear resistance against crushed stone.





HOWO TX 430HP vs Standard 371HP Dump Truck Comparison



For construction sites in Liberia that require a certain level of off-road capability, the HOWO TX's high-horsepower engine, along with tires providing greater load-bearing capacity and high ground clearance, proved highly effective.

Is your construction site short on a HOWO 14CMB mixer truck for pouring concrete? Click here.

Export Case



Country: Liberia

Client Type: Civil Engineering & Construction Contractor

Quantity: 3 Units

Feedback: The truck delivers exceptional power performance, effortlessly navigating out of muddy excavation pits even when fully loaded; the transmission shifts smoothly, significantly reducing driver fatigue.

For more information, please visit



FAQ About HOWO TX Dump Truck.



Q: Who are we?

A: We are TRUCKMAN AUTO,a manufacturer with years of experience in research and development, design, and manufacturing in China



Q: How long is the delivery time for shipping of HOWO TX 6X4 Dump Truck?

A: It depends on the order quantity, and generally takes 15-40 days.



Q: How do we ensure quality of SINOTRUK HOWO TX 430HP Dump Truck?

A: Our products use only genuine, original components from well-known brands and come with official brand warranties. Furthermore, we conduct thorough factory inspections on every product before it leaves the factory.



Q: What’s our MOQ of SINOTRUK HOWO TX 10 Wheels Tipper Truck?

A: For most products, the MOQ is 1 unit.
