380HP SHACMAN E3 8x4 12 Wheels Tipper Truck For Democratic Republic of the Congo

About 380HP SHACMAN E3 8x4 12 Wheels Tipper Truck

SHACMAN E3 tipper truck uses a 300L aluminum alloy fuel tank. The light aluminum alloy reduces the weight of the vehicle and makes it easier for customers to load more cargo. The 300L fuel tank can meet the basic transportation needs of customers. If customers often transport long distances, they can also choose a 400L large fuel tank. The large fuel tank can reduce the number of refueling times for users, reduce costs and increase profits.

380HP SHACMAN E3 8x4 12 Wheels Tipper Truck Specification

Engine: WP10.380E22, 380HP. Euro 2

Cabin: E3 middle long cabin,with one bed, A/C

Gearbox: 10JSD180+QH50, 10F & 2R, with PTO, manual gearbox

Drive Axle: 16 ton MAN double bridge

Tire: 12.00R20, radial tyre, 12+1 pcs

Cargo Size: 7800x2300x1500mm

Fuel Tank:300L

Dimension:10500x2580x3430mm

380HP SHACMAN E3 8x4 12 wheels tipper truck specification only for your reference, we can manufacture other model tipper truck basic your request.

380HP SHACMAN E3 8x4 12 Wheels Tipper Truck Cabin

The cab of the 12 wheels tipper truck adopts a wrap-around center console design, and the instrument adopts a mechanical pointer plus screen design, with the air outlet of the automatic constant temperature air conditioner next to it. The main driving position of the 12 wheels tipper truck adopts an airbag shock-absorbing seat, which makes the driver more comfortable and reduces fatigue during long-distance driving. A full-size berth is placed in the back row for users to rest.

How To Choose The Right Cargo Box shape?

SHACMAN E3 tipper truck can be divided into rectangular cargo box and U-shaped cargo box. The advantages of rectangular cargo box are large loading capacity and strong expandability, but the disadvantage is that the railings of the cargo box are prone to expand when doing some rough engineering work. The advantage of U-shaped cargo box is that it is not easy to cause adhesion during unloading, and the unloading is cleaner. Its U-shaped curved surface can prevent hard collision between stones and the bottom plate of the cargo box. Generally, U-shaped cargo boxes are more commonly used for short-distance transportation such as urban slag and mine ore, while semi-long-distance highway dump trucks mostly use traditional rectangular cargo boxes.
